Aluminium Bay & BOW Windows

Bay & Bow Windows

Aluminium bay or bow windows provide striking, statement glazing features to help you put your stamp on a home. Ideal for both traditional and contemporary properties, they maximise natural light and space. For a high-performance, energy-efficient solution, speak to Atlas today and we’ll connect you with one of our trusted installers.

Why choose atlas?

built for quality

We manufacture to the highest standards using premium materials.

made to perform

Products are secure, thermally efficient, and meet building regulations.

approved installers

Approved partner installers ensure every product is fitted perfectly.

nationwide coverage

We operate across the UK, supporting homes nationwide.

Atlas Bay & Bow Windows

While bay windows offer angular projection with three panels, bow windows have up to five for a curved design. Ideal for new builds, extensions, or simply updating old designs, our gorgeous aluminium range can be customised to your preferences. They’re also compatible with flush casement styles, giving you total flexibility.

Our simple process

Browse our windows,
doors and glazed roof
systems.

Get in touch to
tell us what you’re
interested in.

We’ll match you
with an approved
installer.

Confirm your choice
and look forward to
installation.

Glazed Bay & Bow Windows for Modern Homes

Our glazed bay and bow windows include optional trickle vents, lock upgrades, and thermally broken profiles, delivering excellent energy efficiency, security, weather protection, and long-lasting performance.

Durable

Resistant to rust, warping, and fading for long-term performance.

Energy efficient

WER rating from B to A+ depending on product.

Security certified

PAS24:2022 security available as an upgrade option.

Weatherproof

Air test Class 4, water test E1200 and wind test AE2400

Customisable options

Tailor your aluminium bay and bow windows with our wide variety of styles, colours, handles and glazing options.

Custom styles

Choose from a range of modern and traditional styles.

Multiple colours

Select from a vast palette of single and dual colours.

Handle choices

Pick your perfect arched window handles.

Glazing options

Double glazed and triple glazed options available.

Design configurations

Explore a range of window opening configurations, from side-hung and top-hung designs to fixed, dummy sash and mixed.

side hung

top hung fixed bottom

top hung

Dummy Sash

Fixed

Mixed

Stock colour options

Choose from four stock colours – white, anthracite grey, anthracite grey on white, and black.

White

Grey

Grey on White

Black

Special colour options

Alternatively, select from hundreds of RAL colour options or KL colours for a custom finish.

RAL Colour Range
250+ more

KL Colour Range

Bay & Bow Window Handles

Black, white, grey, polished chrome, satin silver and polished gold TBT handles.

Offset Window Handles

White, black, grey, polished chrome, smooth satin chrome, and polished gold offset handles.

Monkey Tail Handles

Bronze, black, pewter, polished chrome, polished gold, smooth satin and white monkey tail handle colour options.

Pear Drop Handles

Bronze, black, pewter, polished chrome, polished gold, smooth satin and white pear drop handle colour options.

Trickle Vents

Improving indoor air quality, reducing condensation, and maintaining security and heat efficiency.

Quick Glaze Knock-in bead (Alitherm 400)

Designed for faster, easier installation, reducing time on site without compromising quality.

Key Specifications

All our aluminium bay & bow windows meet these standards as a minimum. Certain products are available with additional upgrades or higher performance specifications.

Marine grade polyester powder coating
U value as low as 1.4w/m2k (double glazed) depending on product
U value as low as 1.0w/m2k (triple glazed) depending on product
28mm double glazed or 40mm triple glazed
Side hung max o/a width 864mm

Side hung max o/a height 1400mm
Top hung max o/a width 1400mm
Top hung max o/a height 1500mm
Frame depth 70mm
Optional trickle vents
Air, water and wind tested

Take a look for yourself

Explore our full range of aluminium bay and bow windows to find out more about key design specifications, including opening configurations, glazing, colours and more.

Download Brochure

Frequently Asked Questions

Explore our most frequently asked questions to learn more about aluminium bay & bow windows and their features, lifespan, and advantages.

While aluminium bay and bow windows are both similar in that they protrude from the wall, the shape and panelling are the key differences. Bay windows tend to have three panels, giving a more angular appearance, while bow windows have a minimum of four or five.

Appearing almost circular in nature, bow windows can go around corners and tend to let in more natural light. Bay windows can extend the interior space. There are advantages to both, whether your focus is on space or style. Bay windows are generally considered more contemporary in design while bow windows fit a traditional aesthetic.

Aluminium is ideal for bay window replacements thanks to its durability and energy efficiency. With a longer life expectancy than uPVC, aluminium is weatherproof and secure.

Every Atlas Aluminium bay window is thermally broken, which helps to insulate homes and keep your energy bills low. For a beautiful, customisable aesthetic that lasts for decades, aluminium provides a true return on investment.

All Atlas Aluminium bay and bow fronted windows can be customised to your exacting requirements. This includes sizes, colours, panels, trickle handles, vents and optional upgrades. Our professional teams are on hand to answer any questions you may have about getting your unique design right.

Atlas Aluminium bay and bow windows are very energy efficient thanks to thermal break technology. This means each panel is made with internal barriers to trap air and reduce heat transfer, resulting in low U values and WER ratings from B to A+, depending on the product.

Atlas Aluminium bow and bay windows are installed by our approved teams. When you get in touch, we’ll match you with a verified installer with the right skills to meet your design specifications. We’re on hand to answer any questions you might have about the installation process.

We supply aluminium bay and bow windows throughout the UK, helping you achieve a customised and beautiful look wherever you are.

Discover other Window products at Atlas

What sets Atlas apart

With Atlas, you can guarantee trade-only quality with premium-level support. We’ll listen to your needs and pair you with the best installers up and down the country to help you bring your vision to life.

Every one of our aluminium bay and bow windows has been made to the same high standards. Expect high durability and energy efficiency with a stunning aesthetic finish. For a long-lasting return on investment, get in touch with us today.
